Manual Material Lift Portable Hand Winch Lifter
A Safe and Efficient Lifting Solutio
Manual Material Lifts are versatile, user-friendly devices designed to safely lift, position, and transport heavy materials in a wide range of environments. Ideal for warehouses, offices, industrial sites, and commercial settings, these lifts help reduce physical strain and improve operational efficiency when handling loads.
Key Features:
*Wide Range of Models: Available in various configurations with lift heights , suitable for diverse lifting needs.
*Compact and Portable Design: Lightweight yet robust construction allows for single-person operation. The slim profile fits easily through standard doorways, perfect for tight or confined spaces.
*Easy Manual Operation: Equipped with a hand winch for controlled, secure lifting and lowering of loads.
*Multi-Purpose Use:Ideal for lifting and positioning items such as lighting fixtures, HVAC units, ductwork, or boxed equipment. Perfect for installation, maintenance, and logistics tasks.
Common Applications:
*Warehouses & Distribution Centers:Lifting goods to high shelves or mezzanines for storage or retrieval.
*Offices & Commercial Spaces:Assisting with installation of lighting, signage, or IT equipment.
*Construction & Renovation Projects:Raising tools, panels, or components for building and fit-out tasks.
*Event Setup & Exhibitions:Ideal for lifting structures, signage, and other overhead equipment during setup and teardown.
Manual material lifts provide a safe, efficient, and flexible lifting solution, reducing risk and increasing productivity across a wide range of industries.
Specification:
| Model | ML-STD227 | ML-BR227 | ML-BC227 | ML-STD181 | ML-BR181 | ML-BC181 | ML-STD159 | ML-BR159 | ML-BC159 | ML-SC80 | ML-SC80 |
| Load Cap. | 227kg | 227kg | 227kg | 181kg | 181kg | 181kg | 159kg | 159kg | 159kg | 80kg | 90kg |
| Max. lifting height | Forks Down | 1.2m | 1.2m | 1.2m | 2.5m | 2.5m | 2.5m | 3.0m | 3.0m | 3.0m | 1.1m | 1.6m |
| Forks Up | 1.8m | 1.8m | 1.8m | 3.1m | 3.1m | 3.1m | 3.6m | 3.6m | 3.6m |
| Min. lifting height-Shovel down | 9cm | 5cm | 5cm | 9cm | 5cm | 5cm | 5cm | 5cm | 5cm | 5cm | - |
| Height(Stowed) | 1.70m | 1.70m | 1.70m | 1.70m | 1.70m | 1.70m | 2.0m | 2.0m | 2.0m | 0.85m | 1.13m |
| Length(Working)cm | 88 | 109 | 72 | 88 | 109 | - | - | 109 | 72 | 50 | 76 |
| Length(Stowed)cm | 30.5 | 49 | 72 | 30.5 | 49 | - | - | 49 | 72 | 20 | 38 |
| Outer width(Min.)cm | 63 | 73 | 73 | 63 | 73 | 73 | - | 73 | 73 | 40 | 56 |
| Outer width(Max.)cm | 63 | 110 | 110 | 63 | 110 | 110 | - | 110 | 110 | - | - |
| Inner width(Min.)cm | 34 | 55 | 56.5 | 34 | 55 | 56.5 | - | 55 | 56.5 | - | - |
| Inner width(Max.)cm | 34 | 91.5 | 93 | 34 | 91.5 | 93 | - | 91.5 | 93 | - | - |
| Weight (kg) | 65 | 72 | 174 | 70 | 77 | 179 | - | 80 | 184 | 18 | 30 |
Our Company
Chenlift (Suzhou) Machinery Co Ltd. is a Suzhou-based world-wide supplier of lifting equipment. With over 20 years of experience in the lifting industry, we have the knowledge to assist you in aquiring your next lifting equipment.
We specialize in producing in a range of aerial lift and aerial work platform equipment for your unique application. Based on our own manufacturing experience and refer to European advances design theory and manufacturing technology.
